EXTRACTION ARMS/FITTINGS
TECHNICAL TARGET
Technical Target - an organization which has through professional's - with many decades of versatile experiences in Laboratory projects, such as supply, install & Maintain the lab furniture, besides its related scopes sucha s pre-civil, Eletrical, Machanical, Plumbing, Gas connections etc
FUME EXHAUST-EXTRACTION ARMS
1 Type:
Ceiling mounting Φ88-3/550-450 HMS-PC
Wall mounting Φ88-3/550-450 HM-PC
Deck mounting Φ88-3/350-350 BM-PC
2 Exhaust arm: Includes Φ88mm out fall pipe, plated with aluminium.
3 Joint: With 3 joints made of polycarbonate, each joint can turn 360o and can be detachable
Finger screw: Made in polycarbonate, insert into brass nuts, that can lock once mounted.
Mounted: Stainless steel #304, latch is non-removable and non adjustable, that can be locked at the joints.
Spring: Plated with zinc and stainless steel.
Washer: Made in washer
Air flow valve: Come with rounded joint, can adjust by hand.
4 Fume extraction: Include 88-400/mm polycarbonate limpidity round pide (diameter) in the bottom of the exhaust arm, can be detachable and washed easily.
5 Ceiling column and material:Plated with zinc and stainless steel. Painted with EPOXY, resistant acid. Explanation: To fit laboratory safety required, use non-bumablelastic.
Ceiling mounting Φ88-3/550-450 HMS-PC
Wall mounting Φ88-3/550-450 HM-PC
Deck mounting Φ88-3/350-350 BM-PC
2 Exhaust arm: Includes Φ88mm out fall pipe, plated with aluminium.
3 Joint: With 3 joints made of polycarbonate, each joint can turn 360o and can be detachable
Finger screw: Made in polycarbonate, insert into brass nuts, that can lock once mounted.
Mounted: Stainless steel #304, latch is non-removable and non adjustable, that can be locked at the joints.
Spring: Plated with zinc and stainless steel.
Washer: Made in washer
Air flow valve: Come with rounded joint, can adjust by hand.
4 Fume extraction: Include 88-400/mm polycarbonate limpidity round pide (diameter) in the bottom of the exhaust arm, can be detachable and washed easily.
5 Ceiling column and material:Plated with zinc and stainless steel. Painted with EPOXY, resistant acid. Explanation: To fit laboratory safety required, use non-bumablelastic.
WATER FLOW FAUCET SERIES
Adopt pure brass, By acid proof alkali powder paint hot solid disposal, prevents sour alkali, endures
cauterization.
Handle is adopted with imported ceramic headwork. Resistant to most chemicals.
Water Outlet is made in brass or PP, Possesses slow down press effect, can disassemble washing, at random
replacing vaporous water outlet.
Gooseneck Spout: 360° swing.
Executes Standards
Joint: G3/8, G 1/2 & G3/4 accords with standard UNI ISO228/1 Water outlet: accords with standard KIN12898
Max. work pressure: 10 bar
Handle indication accords with standard DIN12920 Noise accords with standard DIN4109 Safety indication
accords with standard DIN1988
